ULTIMI ANNUNCI

AGGIUNGI ANNUNCIO

Rimuovi filtro

Prezzo:

Video

OKUMA MA 600HB

19 novembre 2020 alle ore 12:25:39

Year of manufacture: 2008
CNC Control: OKUMA OSP-P200

Axes
X-axis travel mm: 1000
Y-axis travel mm: 900
Z-axis travel mm: 1000
B-axis degree: 1º
Distance form pallet surface to spindle center mm: 50 – 950
Distance from the spindle nose to the center of the pallet mm: 70-1070
Feed max. mm / min: 0 – 60.000
Rapid traverse rate max. m / min: 60
Motor power Kw (X-Y-Z): 6,7-6-6.7
Positioning accuracy X-Y-Z mm.: 0,004
Positioning repeatability X-Y-Z mm. : 0,0015/100

Palette
Type: pitch 125 perforated M16 (T slots)
Dimensions mm: 630 x 630
Workpiece weight max. kg: 1200
Maximum workpiece swing diameter mm: 1000
Maximum workpiece height mm: 1.000
Pallet indexing time sec.: 7
Index time (90º - 180º) sec.: 2-3

Spindle
Spindle speed rpm: 12.000
Spindle drive power kW: 30/22
Max torque at the spindle Nm: 284

Tooling system
Type of spindle taper hole: BT. 50
Tool magazine: Chain
Magazine slots St .: 100
Diameter max. mm: 140
Diameter with free adjacent seats mm: 150
Length max. mm: 300
Tool changing time (tool to tool) sec.: 1,9
Tool changing time (chip to chip) sec.: 4,4
Max tool weight kg: 25
Air pressure bar. : 4-6

Cooling system
Internal spindle cooling
Pressure bar: 20


Equipment
MAYFRAN chip conveyor
APC 10 pallet
Presetting

Machine running times
Main switch ON Std .:
Operating time .:

Basic machine dimensions / weight
Length mm: 6.110
Width mm: 3.380
Height mm: 3.280
Weight kg: 24.000

3 Axis Group (Fernando)

Nome:

+4916096787736

info@3axis-group.com

E-Mail:

Indirizzo:

Fortuna Park Flinger Broich 203, Halle 7-K 40235 Düsseldorf Germany

Tel:

Prezzo:

Video

MAKINO F09

19 novembre 2020 alle ore 12:23:24

Year of construction: 2016
CNC control: FANUC Professional 5

Axes
X mm: 1600
Y mm: 800
Z mm: 650
Feed mm / min: 24,000
Rapid scroll max. m / min: 24

Pallet
Dimensions mm: 1850 * 800
Workpiece weight max. kg: 2500

Spindle
Spindle speed rpm: 10,000
Spindle drive power kW: 37

Tool system
Cone Type: HSK-100
Charger type: Chain
Tool magazine capacity: 30
Maximum tool diameter mm: 200
Workpiece dimensions plus. Mm: 1850 * 800 * 550
Tool weight max. kg: 20
Tool change time. s:

Refrigeration system
Cooling through the spindle:

equipment
Chip extractor

Machine run times
Operating time:
Processing time:

Basic machine dimensions / weight
Length mm:
Width mm:
Height mm:
Weight kg: 17.000

3 Axis Group (Fernando)

Nome:

+4916096787736

info@3axis-group.com

E-Mail:

Indirizzo:

Fortuna Park Flinger Broich 203, Halle 7-K 40235 Düsseldorf Germany

Tel:

Prezzo:

Video

MORI SEIKI NVX5100II-40

19 novembre 2020 alle ore 12:14:49

Year of construction: 2013
CNC control: M750BM with MAPPS II

Axes
X mm: 1,050
Y mm: 530
Z mm: 510
Speed max. mm / min: 30000
Rapid scroll max. m / min: 30

Work table
Table dimension mm: 1.350x600
Workpiece weight max. kg: 1,200

Spindle
Spindle speed rpm: 13,000
Spindle power kW: 18.5
Connected load. kVA: 30

Tool system
Tool holder: SK-40
Tool magazine capacity pos .: 30
Tool changer: double clamp
Tool diameter mm: 120
Tool diameter with free adjacent places mm: 240
Tool length max. mm: 350
Tool weight max. kg: 8

Refrigeration system
Cooling through spindle:
Refrigerant tank l .:

Equipment
Spiral chip extractor, in the workspace,
Renihaw probe pre-installation (probe not included).
USB connection
Network cable connection (RJ-45)
Toolbrake
Pre installation Internal cooling
Manuals

Hours of machine operation
Ignition time:
Cutting time:

Basic machine dimensions / weight (workspace)
Length mm: 4150
Width mm: 3550
Height mm: 2800
Weight kg: 7,260

Transport dimensions
Machine: 2900 * 2900 * 2800, 7260kg
Chip extractor: 1500 * 4150 * 1840, 310kg
Transformer: 600 * 440 * 800, 180kg
Stair: 800 * 1050 * 1700

3 Axis Group (Fernando)

Nome:

+4916096787736

info@3axis-group.com

E-Mail:

Indirizzo:

Fortuna Park Flinger Broich 203, Halle 7-K 40235 Düsseldorf Germany

Tel:

Prezzo:

Video

OKUMA 600HB

19 novembre 2020 alle ore 12:12:50

Year of manufacture: 2007
CNC Control: OKUMA OSP-P200

Axes
X-axis travel mm: 1000
Y-axis travel mm: 900
Z-axis travel mm: 1000
B-axis degree: 1º
Distance form pallet surface to spindle center mm: 50 – 950
Distance from the spindle nose to the center of the pallet mm: 70-1070
Feed max. mm / min: 0 – 60.000
Rapid traverse rate max. m / min: 60
Motor power Kw (X-Y-Z): 6,7-6-6.7
Positioning accuracy X-Y-Z mm.: 0,004
Positioning repeatability X-Y-Z mm. : 0,0015/100

Palette
Type: pitch 125 perforated M16 (T slots)
Dimensions mm: 630 x 630
Workpiece weight max. kg: 1200
Maximum workpiece swing diameter mm: 1000
Maximum workpiece height mm: 1.000
Pallet indexing time sec.: 7
Index time (90º - 180º) sec.: 2-3

Spindle
Spindle speed rpm: 6000
Spindle drive power kW: 30/22
Max torque at the spindle Nm: 606

Tooling system
Type of spindle taper hole: BT. 50
Tool magazine: Chain
Magazine slots St .: 60
Diameter max. mm: 140
Diameter with free adjacent seats mm: 150
Length max. mm: 300
Tool changing time (tool to tool) sec.: 1,9
Tool changing time (chip to chip) sec.: 4,4
Max tool weight kg: 25
Air pressure bar. : 4-6

Cooling system
Pressure bar: 15

Equipment
MAYFRAN chip conveyor
Renishaw probe
Presetting
2 Palets

Machine running times
Main switch ON Std .:
Operating time .:

Basic machine dimensions / weight
Length mm: 6.110
Width mm: 3.380
Height mm: 3.280
Weight kg: 24.000

3 Axis Group (Fernando)

Nome:

+4916096787736

info@3axis-group.com

E-Mail:

Indirizzo:

Fortuna Park Flinger Broich 203, Halle 7-K 40235 Düsseldorf Germany

Tel:

Prezzo:

Video

QUASER MV204IIU

19 novembre 2020 alle ore 12:04:28

Year of Manufacturing: 12/2002
Controller: HEIDENHAIN iTNC530

Axis
X-axis travel mm: 700
Y-axis travel mm: 590
Z-axis travel mm: 480
A axis table Swivelling range degree: +- 110
C axis table turning degree: 360
Feedrate mm/min:
Rapid traverse mm/min: X,Y,Z 32.000

Working table / pallets
Dimensions mm: dia 280
Opc A: ø500 (included)
Opc B: 600 x 400 (included)
Table load max. kg: 265
Load Opc A kg: 200 (included)
Load Opc B kg: 200(included)

Spindle
Spindle rpm: 10.000
Spindle drive power kW: 15 / 33
Torque Nm: 192 / 189

Tool System
Taper: BT-40
Tool magazine system: RANDOM
Tool magazine places: 32
Tool changer: Double gripper
Tool dia mm:
With free adjacent tool places mm:
Tool length max. mm: 300
Tool weight max. kg: 7

System
Nozzle coolant
Coolant through spindle bar: 20
Coolant tank liter: 280

Equipment
Varios optional table configurations for miscellaneous application: Standard ø280, Opc 	A ø500, Opc B 600 x 400
Chip conveyor
Coolant through spindle
Work light
Manuals


Running hours
Power on: 13.975
Spindle time: 6.258

Basic machine dimensions / Weight
Lengths mm: 2.220
Widths mm: 2.650
Height mm: 2.855
Weight kg: 8.200

3 Axis Group (Fernando)

Nome:

+4916096787736

info@3axis-group.com

E-Mail:

Indirizzo:

Fortuna Park Flinger Broich 203, Halle 7-K 40235 Düsseldorf Germany

Tel:
